Double Safety for 1,500°C Steel · Zero Failure Design · Certified for Life-Critical Lifts
|
Feature
|
How It Protects Lives
|
|---|---|
|
Dual brakes
|
Two separate brake systems – both must fail for load to drop (probability: 1 in 10 million)
|
|
Dual ropes
|
Two independent ropes wound on separate drums – each can hold full ladle weight
|
|
Heat shield
|
Stainless steel barrier between ladle and hoist – keeps motor below 80°C even at 5m distance
|
|
Overspeed governor
|
Auto-brakes if ladle descends too fast (e.g., brake fade from heat)
|
|
Load monitoring
|
Alarm sounds if ladle weight exceeds 90% capacity – prevents overload
|
|
Parameter
|
Range/Details
|
|
|---|---|---|
|
Rated Lifting Capacity
|
2T – 10T
|
|
|
track
|
25a-45a | |
|
Lifting Height
|
9m – 27m
|
|
|
Working Class
|
M6
|
|
|
Lifting Speed
|
0.7/7(m/min)
|
|
|
Trolley Traveling Speed
|
20m/min
|
|
|
Lifting Power
|
1.5/13kW | |
| Traveling Power |
0.8*2kW
|
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
|
|
Control Mode
|
Ground pendant control/Remote control
|
|
|
Working Temperature
|
-20℃ – +45℃
|
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments
|
