Two Independent Hoists • Lift Two Loads OR Balance One Long Load • 100% New
|
Need
|
QE Solution
|
|---|---|
|
“Need to lift two items at once”
|
Two independent winches – lift two molds, two machines, or parts + tools simultaneously
|
|
“Lifting long beams/pipes – single hook causes tilt”
|
Synchronized mode – both winches lift together, perfectly balanced. No bending or swing
|
|
“Don’t want two separate cranes”
|
One crane does both jobs. Saves 40% cost vs. buying two single-hook cranes
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
5+5T -16+16T
|
|
Span Length
|
10m -31.5m
|
|
Lifting Height
|
6m – 16m
|
|
Working Class
|
A5/A6
|
|
Lifting Speed
|
Single speed: 7.2m/min- 15.5m/min |
|
Trolley Traveling Speed
|
37.2m/min-39.7m/min
|
|
Crane Traveling Speed
|
30m/min-93.7m/min |
|
Control Mode
|
Remote control/air operation
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
|
Steel track
|
QU70
|
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments
|
