Heavy Duty • 30% Lighter • Low Headroom • 100% New
|
Need
|
QDXX Solution
|
|---|---|
|
“Lifting 10–100 tons daily”
|
Double girder strength – handles heavy molds, machines, coils reliably
|
|
“Building cost too high for heavy crane”
|
30% lighter structure vs. traditional → saves steel + lowers workshop cost
|
|
“Workshop height limited (<12m)”
|
Ultra-low headroom – 1.2m vs. 2.0m → more usable lift in same building
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
5T – 50T
|
|
Span Length
|
10m – 31m
|
|
Lifting Height
|
6m -17m
|
|
Working Class
|
A5
|
|
Lifting Speed
|
Single speed: 0 m/min – 10 m/min
|
|
Trolley Traveling Speed
|
2-20m/min
|
|
Crane Traveling Speed
|
3-32m/min
|
|
Control Mode
|
Remote control/air operation
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
|
steel track
|
P43 |
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments
|
