Problem
|
MH Solution
|
|---|---|
|
No factory building for indoor crane
|
Self-standing gate – works on flat ground. No roof needed
|
|
Need crane for yard/stockpile
|
Moves on rails – covers open areas easily
|
|
Budget tight for heavy structure
|
Single girder = lowest cost gantry. Same power, less steel
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity (Per Hoist)
|
3T-32T
|
|
Span Length
|
14m – 35m
|
|
Lifting Height (Per Hoist)
|
6m – 12m
|
|
Working Class
|
A3 – A4
|
|
Lifting Speed
|
Single speed 3m- 8m/min; Dual speed 0.3/3m-0.8/8m/min
|
|
Trolley Traveling Speed
|
5m/min – 30m/min
|
|
Crane Traveling Speed
|
10m/min – 30m/min
|
|
Control Mode
|
Cab control/ Wireless remote control
|
|
Power Supply
|
380V/50Hz/3Phase
|
|
Girder Material & Type
|
Q235B High-Strength Steel
|
|
Working Temperature
|
-25℃ +40℃
|
|
Protection Grade
|
IP55 ; IP54
|
