Fits Tight Spaces · Full Lifting Power · No Wasted Ceiling Height
|
Feature
|
What It Means for You
|
|---|---|
|
Ultra-low profile
|
Only 580–720mm headroom needed (vs. 900mm+ for standard hoists). Perfect for workshops under 4m height.
|
|
M3 vs. M4 – Pick Your Fit
|
• M3 (DJCDDJMD): Single-motor design – simple, cost-effective for 3–5t
• M4 (FMDJCDFMDJMD): Dual-motor design – smoother lifting for 5–10t heavy-duty use |
|
European compact layout
|
Motor + gearbox integrated inside drum. No bulky parts hanging down.
|
|
100% brand new
|
Factory-direct from Feima Crane. CE & ISO certified. 2-year warranty. No used/rebuilt units.
|
|
Plug & play
|
Mounts directly on single-girder crane. Ready to lift in under 30 minutes.
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
2 – 16T
|
|
track
|
25a-45a |
|
Lifting Height
|
6m – 12m
|
|
Working Class
|
M4
|
|
Lifting Speed
|
0.35/3.5(m/min)
|
|
Trolley Traveling Speed
|
20m/min
|
|
Lifting Power
|
3.0-13kW |
| Traveling Power |
0.4-0.8*2kW
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
|
Control Mode
|
Ground pendant control/Remote control
|
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments
|
