No Factory Building Needed • Outdoor Ready • Low Cost • 100% New
|
Feature
|
What It Means for You
|
|---|---|
|
Full explosion-proof design
|
Motor, control box, limit switch, and trolley wheels all certified—no spark risk even in gas/dust zones
|
|
M3 vs. M4 – Right Protection for Your Site
|
• M3 (HBHBS): For gas zones (Zone 1/2) & light dust areas – 3–5t capacity
• M4 (FMHBFMHBS): Heavy-duty dual-motor for high-risk zones (Zone 1 + Zone 21/22) – 5–10t capacity |
|
Certified safety
|
Meets ATEX, IECEx & GB3836 standards. Certificate provided with every unit.
|
|
Special safety features
|
• Copper-alloy wheels (no friction sparks)
• Sealed electrical compartments • Thermal overload protection |
|
100% brand new
|
Factory-direct from Feima Crane. Full documentation for customs & safety audits. 2-year warranty.
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
0.5T – 32T
|
|
track
|
25a-45a |
|
Lifting Height
|
6m – 30m
|
|
Working Class
|
M4
|
|
Lifting Speed
|
0.3/3(m/min)
|
|
Trolley Traveling Speed
|
20m/min
|
|
Lifting Power
|
0.8-18.5kW |
| Traveling Power |
0.2-0.8*4kW
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
|
Control Mode
|
Ground pendant control/Remote control
|
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments
|
Not sure which product fits your needs?
Submit the form below and our engineers will design a customized solution for you at no extra cost.
