Danger in Steel Plant
|
LHY Protection
|
|---|---|
|
Molten steel ladle falling
|
→ Dual independent brakes on main hoist – stops even if one fails
|
|
High temperature melts cables
|
→ Heat-resistant cables + thermal shields (works at 400°C+)
|
|
Heavy daily use breaks cranes
|
→ A7–A8 duty class – built for 24/7 operation in harsh conditions
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity5
|
2T – 10T
|
|
Span Length
|
7.5m – 31.5m
|
|
Lifting Height
|
6m – 24m
|
|
Working Class
|
A6 – A8
|
|
Lifting Speed
|
Single speed: 3m/min – 8m/min; Dual speed optional (0.8m/min -8m/min)
|
|
Trolley Traveling Speed11-21
|
20m/min
|
|
Crane Traveling Speed
|
20m/min
|
|
Control Mode
|
Remote control
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
|
Insulation class
|
H级
|
|
Working Temperature
|
-20℃ – +45℃
|
