Problem
|
LDZ Solution
|
|---|---|
|
“Workers shovel coal/sand all day – slow & tiring”
|
→ Grab opens/closes automatically. One button lifts 1–5 m³ per cycle
|
|
“Need crane for loose materials (not hooks)”
|
→ Comes with grab bucket – perfect for coal, sand, gravel, scrap
|
|
“Limited budget for small warehouse”
|
→ Single girder design = 30% cheaper than double girder. Same power
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
1T – 10T
|
|
Span Length
|
7.5m – 31.5m
|
|
Lifting Height
|
6m – 12m
|
|
Working Class
|
A4
|
|
Lifting Speed
|
Single speed: 16m/min
|
|
Trolley Traveling Speed
|
20m/min
|
|
Crane Traveling Speed
|
30m/min
|
|
Control Mode
|
Handle/Remote control/Air operation
|
|
Power Supply
|
380V-50Hz-3Phase /Customizable
|
| Steel track | QU70 |
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments
|
| Insulation class | F级 |
