35+ Years
Industry Expertise
120,000 m²
Modern Manufacturing Base
8,000+ Cases
Global Safe Deliveries
Industry Expertise
Modern Manufacturing Base
Global Safe Deliveries
|
Challenge
|
LDY Solution
|
|---|---|
|
“Moving molten steel / hot ingots – safety is #1”
|
→ Dual braking system on hoist (2 independent brakes). Stops even if one fails
|
|
“High temperature damages normal cranes”
|
→ Heat-resistant design: special paint, insulated cables, thermal protection
|
|
“Heavy daily use breaks cheap cranes”
|
→ Heavy-duty work class A6–A7. Built for 20+ lifts/hour, 365 days/year
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
1T – 10T
|
|
Span Length
|
7.5m – 31.5m
|
|
Lifting Height
|
6m – 24m
|
|
Working Class
|
A6 – A7
|
|
Lifting Speed
|
Single speed: 8m/min
|
|
Trolley Traveling Speed
|
20m/min
|
|
Crane Traveling Speed
|
20m/min
|
|
Control Mode
|
Remote control
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
| Insulation class | H级 |
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP54 (Standard); IP65 optional for dusty/humid environments
|
Not sure which product fits your needs?
Submit the form below and our engineers will design a customized solution for you at no extra cost.
