Problem
|
LDP Solution
|
|---|---|
|
“Workshop has wall/column on one side only”
|
→ Crane hangs from one side only – no support needed on the other side
|
|
“Too narrow for normal bridge crane”
|
→ Works in tight spaces. Only needs support on one edge
|
|
“Wasted corner space”
|
→ Turns dead corners into usable lifting zones
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
2T – 16T
|
|
Span Length
|
7.5m – 31.5m
|
|
Lifting Height
|
6m – 30m
|
|
Working Class
|
A3 – A4
|
|
Lifting Speed
|
8/0.8m/min
|
|
Trolley Traveling Speed
|
20m/min
|
|
Crane Traveling Speed
|
20m/min
|
|
Control Mode
|
Handle/Remote control
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
| Steel track | QU70 |
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments
|
| Insulation class | F级 |
