Reliable • Space-Saving • Cost-Effective • CE Certified
|
Feature
|
Benefit to Your Business
|
|---|---|
|
Compact Design
|
Ideal for workshops with limited headroom (≤10m). Saves up to 30% building height vs. double-girder cranes.
|
|
Lightweight Yet Strong
|
Q235B steel main girder + optimized box structure. Handles 1–20 tons with minimal deflection.
|
|
Energy Efficient
|
Low-power motors (380V/50Hz) cut electricity costs by ~25% vs. older models.
|
|
Quick Installation
|
Modular components + pre-assembled trolleys. Ready to operate in 3–5 days.
|
|
100% New Equipment
|
Factory-direct production—no used/refurbished units. Full traceability & 2-year warranty.
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
1T – 16T
|
|
Span Length
|
7- 31m
|
|
Lifting Height
|
3-30m
|
|
Working Class
|
A3/A4/A5
|
|
Lifting Speed
|
Single speed: 3 – 8m/min; Dual speed optional 0.8/8 (m/min )
|
|
Trolley Traveling Speed
|
20/30 m/min
|
|
Crane Traveling Speed
|
20/30 m/min
|
|
Control Mode
|
Remote control/Handle
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
|
Girder Material
|
Q235B High-Strength Structural Steel
|
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments
|
