Traditional Crane
|
FMLH European Advantage
|
|---|---|
|
Heavy structure → high building cost
|
30% lighter girders → saves steel + lowers workshop construction cost
|
|
Wastes headroom → less usable lift height
|
Ultra-low headroom design → 0.8m vs. 1.5m → more lift in same building
|
|
High power use → expensive to run
|
IE3 efficient motors → 15% less electricity per year
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
3T – 50T
|
|
Span Length
|
7m – 31m
|
|
Lifting Height
|
6m – 18m
|
|
Working Class
|
A5
|
|
Lifting Speed
|
Single speed: 0-3m/min ; Dual speed optional 0.8/5(m/min )
|
|
Trolley Traveling Speed
|
5-20m/min
|
|
Crane Traveling Speed
|
3-30m/min
|
|
Control Mode
|
Remote control/handle/air operation
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
|
Girder Material
|
Q235B High-Strength Structural Steel
|
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments30% Lighter • Low Headroom • Energy Saving • 100% New
|
