Problem
|
ANTOP Solution
|
|---|---|
|
“Ceiling too low for wire rope hoist”
|
→ Chain design = 30% shorter – fits workshops under 8m height
|
|
“Wire rope breaks, needs frequent replacement”
|
→ Alloy steel chain lasts 2–3x longer – no snapping, less downtime
|
|
“Need simple, reliable lifting”
|
→ One button up/down. Built-in brake holds load when power off
|
|
Parameter
|
Range/Details
|
|---|---|
|
Rated Lifting Capacity
|
3T – 30T
|
| Chain mode | 3-8chain |
|
Lifting Height
|
3m – 12m
|
|
Working Class
|
M3
|
|
Lifting Speed
|
Single speed:1.3m/min – 2.2m/min
|
|
Trolley Traveling Speed
|
11/21m/min
|
|
Crane Traveling Speed
|
30m/min
|
|
Control Mode
|
Ground pendant control/Remote control
|
|
Power Supply
|
380V/50Hz/3Phase /Customizable
|
|
Girder Material
|
Q235B High-Strength Structural Steel
|
|
Working Temperature
|
-20℃ – +45℃
|
|
Protection Grade
|
IP44 (Standard); IP65 optional for dusty/humid environments
|
