Steel Scaffold System is intended for special industrial access, lifting and supporting applications. Available configurations include capacity: 270 kg/m² (heavy-duty) / 150 kg/m² (standard); lifting height: 30 m (with proper bracing). The final configuration should be matched to the actual load, site layout and operating frequency.
Typical Applications
Special industrial access, lifting and supporting applications.
What to Confirm Before Ordering
- Confirm the required dimensions, load rating and connection details.
- Share equipment drawings or clear photos so interfaces can be checked.
- Specify the working environment, operating frequency and required standards.
Send us your project requirements and available drawings. Our engineers will check the main dimensions, duty class and safety configuration before quotation.
| Wobbly platforms = safety risk | Locking wedge connection – zero looseness, tested to 3x safety factor |
|---|---|
| Type | Ringlock / Cuplock / Frame scaffolding (choose your style) |
| Material | Q235B / Q345B steel tube (Ø48.3×3.25mm) |
| Max Height | 30 m (with proper bracing) |
| Load Capacity | 270 kg/m² (heavy-duty) / 150 kg/m² (standard) |
| Surface | Hot-dip galvanized (15+ years rust protection) |
| Components | Standards, ledgers, transoms, braces, base jacks, boards |
| Certification | EN 12811, OSHA compliant, ISO 9001 |
What information is needed to select the right Steel Scaffold System?
Please share the required load, key dimensions, operating frequency, power supply and working environment. Drawings or site photos help us confirm the configuration.
Can the Steel Scaffold System be customized?
Yes. Dimensions, materials, speeds, controls and protection options can be matched to the project after technical review.
